Veeder-Root Pulse Transmitters for Meter Registers

Pulse transmitters that turn a meter register’s mechanical count into electronic pulses, so every delivery can be read on a remote display or fed straight into a data system.

1, 10 or 100 pulses per revolution
Dry reed (1871) or solid-state (7671) designs
Dual-channel 50 ppr option on the 7671
Links registers to remote displays & data systems

Request a Quote Talk to an Engineer

Description

Veeder-Root Pulse Transmitters for Meter Registers

Connect a Veeder-Root meter register to a remote display, totaliser or data monitoring system with the 1871 and 7671 pulse transmitters. These units convert register movement into electronic pulses for remote measurement and recording.

1871 Dry-Reed Pulse Transmitter

The 1871 uses a dry-reed switch, magnet and synchronised gear train to provide 1 or 10 pulses per revolution. It switches an input voltage to produce a square-wave signal with minimal contact bounce for compatible electronic circuits.

7671 Solid-State Pulse Transmitter

The 7671 uses magnetic sensing without moving electrical contacts. It provides 100 pulses per revolution in single-channel operation, or 50 pulses per revolution in dual-channel operation.

Both models support remote indication, totalising and delivery data monitoring.

Shipping Information

Customised or made-to-order products may require additional time for assembly, testing and preparation before dispatch. In-stock items are available for next-day delivery.

As lead times can vary depending on your chosen product specifications, please contact us for an estimated dispatch and delivery time before placing your order if timing is important.

Download Technical Datasheet

veeder-root-7671-baseefa-solid-state-pulse-transmitter-datasheet-bms pdf veeder-root-1871-baseefa-pulse-transmitter-datasheet-bms pdf
